Name: 100W Co2 laser marking machine
Brand: JINAN LANSEN LASER EQUIPMENT CO., LTD
Availability: InStock
Rating: 5 (1 reviews)

100W Co2 laser marking machine

Davi RF Laser Marker applications as following:

Co2 laser markers are widely used in the field of non-metal field, such as: garment & shoes engraving, fabric cutting, medical packaging, handicrafts & gift, food printing, soft drink printing, cigarette code, beverage packaging tobacco printing, rubber marking machine, acrylic marker, water bottle marker, marking on plastic, leather engraving industries.

CO2 laser marking machines with CO2 radio frequency laser tube can have thin laser beam, better marking effect, can make marking more convenient. It has long life span, fast speed, fine lines and stable performance, can be widely applied in production line.

Description
Parameter

Lansen Coherent RF Co2 Laser Marking machine fetures:

1. Co2 laser markers take RF metal laser tube as the laser source. By 2D fast-speed scanning mirrors swinging as the scheduled angles under the controlling of the computer, the laser focus on the surface of the work piece by focus lens to form images and realize marking and graph processing.
2. RF metal tube has exquisite beam quality, stable power output, high marking precision, long working life time, and can work for 3-5 years free of maintenance, then can be recharged by re-filling with co2 gas, suitable for users requiring batch production and high marking precision. Once invested, whole-life benefited.
3. Using digital fast-speed scanning laser head, it can be the graph in shortest time to finish fine marking process.
4. Simple structure, abrasion and rusty against component, the system have the most stable performance and moving precision.
5. It can configure automatic fixture, baiting production line.

Laser Power	100w
Laser Wavelength	10.6μm
Laser Repetition Frequency	s25KHZ
Marking Area	200mm*200mm
Linear Speed	57000mm/s
Min.Line Width	0.1mm
Min Letter	0.4mm
RepeatableAccuracy	±0.01mm
Gross Power	1.5KW
Power Requirement	220V/50Hz
Cooling System	Air Cooling/Water Cooling
Graphic Format Supported	BMP,JPG,GIF,TGA,PNG,TIG,Al,DXF,DST,PLT,ETC
Machine size(weight)	1380mm770mm1780mm(272kg)
CW6000water chiller(weight)	670mm470mm890mm(60kg)

Laser power	Metal RFtube(China orimported)
Laser Wavelength	10.6μm
Laser Repetition Frequency	s25KHZ
MakingArea	100mm100mm/200mm200mm/300mm*300mm
MakingDepth	s0.3mm(adjustable accordingto materials
Linear Speed	s7000mm/s
Min.LineWidth	0.1mm
Min.Letter	0.4mm
Repeatable Accuracy	±0.01mm
Gross Power	1.2KW
Electricity Source	220V/50Hz/8A
CoolingSystem	Air Cooling
Suitable for	Nonmetal materials marking or leather cloth quickly cutting
