FEATURE
* cast iron Frame, platform movement, rail support surface stability.
* Heavy frame with Semi-closed structure
* Three-axis full dust proof and waterproof structure, screw guide rails with automatic oiling system to ensure that the screw guide rail can work for a long time does not rust.
* Spindle selection for high torque spindle motor specially for mould work, high rotating speed, rotating vibration is small
noise, low working noise.
* Equipment X, Y, Z three axes adopt Hiwin linear guide rail, load-bearing redundancy, long life, for a high degree of CNC
equipment, square linear guide rail life than long, high precision.
* Machine adopts Yaskawa servo motor, with high speed and higher precision.
* TBI ballscrew transmit way
* NK260 NC Studio Controller, powerful function, and hand wheel control way.
* Oil lubration system
* With Tool sensor to help operation.
* equipment operation is more simple, more user-friendly design, so that you use the process more conveniently.
* In strict accordance with the European CE standard manufacturing;
|
Performance |
Performance-1 |
parameter |
|
Trave |
X |
600mm |
|
|
Y |
600mm |
|
|
Z |
200mm |
|
Working area |
|
400x400mm |
|
Precision |
Engraving precision |
±0.05mm |
|
|
Repeatability precision |
±0.01mm |
|
Structure |
Bed and table structure |
cast iron |
|
|
X,YZ Structure |
X.YZ screw |
|
Speed |
Empty line speed |
8000mm/min |
|
|
Working speed |
4000mm/min |
|
Spindle |
Spindle power |
1500W |
|
|
Spindle speed |
0-24000r/min |
|
Running mode |
|
Stepper motor |
|
Voltage |
|
AC220V/50Hz |
|
Command |
|
G Code |
|
Control system |
|
Ncstudio control system |
