The Fiber Laser Marking machine for metal adopts international most advanced technology and the fiber laser source's lifetime can reach 100,000 hours, 5-6 years without any consumables and maintenance
Advantages
1).Wide range: Can be used on many materials like metal, plastic, leather, alloy etc.
2).Permanent marking: It won’t fade, run or become less discernable as time passes.
3).Long service time: Fiber laser model has a over 100,000 hours working life. Almost no maintenance during this period.
4).Easy to operate: Support almost any Windows-based software like Coreldraw,AutoCAD, Photoshop.
5).High precision: 0.003mm re-position accuracy. Minimum line width 0.01mm.
6).Non-contact process: Won’t cause mechanical extrusion or mechanical stress to materials.
|
Laser Power |
20w |
30w |
50w |
100w |
||
|
Laser Wavelength |
1064nm |
|||||
|
Q-frequency |
20KHz-30KHz |
|||||
|
Divergence |
0.3mard |
|||||
|
Marking Range |
112*112mm |
|||||
|
Minimum LineWidth |
0.02mm |
|||||
|
Minimum Character |
0.15mm |
|||||
|
Marking Depth |
0~0.5mm |
|||||
|
Engraving Line Speed |
≤7000mm/s |
|||||
|
Repeatability Accuracy |
±0.001mm |
|||||
|
Beam Quality |
M2:1.2~1.8 |
|||||
|
Marking Format |
Graphics,Text,BarCodes,Two-dimensional Code,Automatically |
|||||
|
Graphic Format Supported |
BMP IPG,GIF,TGA.PNG,TIF.AI,DXFDST₂PLTetc |
|||||
|
Working Voltage |
220V±10%/50Hz4A |
|||||
|
UnitPower |
<0.5kw |
|||||
|
Use of theEnvironment |
Clean and Dust Free o Dustless |
|||||
|
Working Condition Humidity |
5%-75%.Free of Condensed Water |
|||||
|
Laser ModuleLife |
>100000 hours |
|||||
|
Laser Source |
RAYCUS/JPT M7 |
|
Beam quality |
M2<1.8 |
|
Laser wavelength |
1064±1nm |
|
Power adjustment range |
10~100% |
|
Frequency ofpulse |
20~250KHz |
|
Power supply |
220V/50Hz(110V/60Hzcan choose) |
|
Cooling system |
Air Cooling |
|
Marking content suppor |
import vector files lke PLT |
|
|
Add Text,series number,etc.inSHX,TTFand CSF |
|
|
Add Barcode,QR code |
|
Working area |
110*110mm(Standard) |
|
Marking depth |
<1mm |
|
Marking speed |
<7000mm/s |
|
Min.line width |
0.05mm |
|
Repeatability accuracy |
0.003mm |
|
Power Machine |
300W-800W(Depend onfiber laser power) |
|
Operation temperature |
-15~+60*C |
|
Operating environment |
Clean and free of dust |
|
Warranty |
18 Months forlaser source,2 years for machine |
|
Optional |
Conveyor belt at differentsize/C02 laser source fornonmetal/Auto feeding |
|
Model |
LSD DiskLaser Marking Machine |
|
Type |
Standby |
|
Computer |
ncludes PC |
|
Mode of operation |
Pulsed |
|
Polarization |
random |
